Draftex Plan Trolleys Starting from $232.00

  • Dpta110 Draftex A1 Plan Trolley 10 Clamp Capacity
  • Dpta1 Draftex A1 Plan Trolley 20 Clamp Capacity
  • Dpta010 Draftex A0 Plan Trolley 10 Clamp Capacity
  • Dpta0 Draftex A0 Plan Trolley 20 Clamp Capacity

Draftex Plan Filing Trolleys are strong while lightweight with castor mobility and designed for front loading plan filing clamps which in turn suspend drawing plans.

  • A0 Size in 20 or 10 Clamp Capacity.
  • A1 Size in 20 or 10 Clamp Capacity.
  • Very Strong and Robust with Excellent Stability.
  • Clamp Support Panel is Manufactured with Heavyweight Pressed Steel, Providing Exceptional Stability and Load Capacity.
  • Loaded Trolleys use Less Floor Space than other Brands.
  • Very Easy to Assemble.
  • Real Value for Money.
  • Finished in Chip Resistant Grey Powder Coat
  • Fitted with Four Lockable Castors for Easy Mobility.
  • Compatible with Draftex and Planhorse Clamps.

Assembled Dimensions as follows:

Model Capacity Dimensions
DPTA110 (10 Clamps) 1050H x 425W x 620D
DPTA1 (20 Clamps) 1050H x 760W x 620D
DPTA010 (10 Clamps) 1350H x 425W x 620D
DPTA0 (20 Clamps) 1350H x 760W x 620D
For Information and Pricing on our Range of Draftex Plan Clamps to Suit Click here

Draftex Plan Filing Trolleys are strong and robust.
A heavy duty pressed and welded section of steel forms the main support bracket.
The practicality of the front loading design ensures that clamps, once removed can be replaced in the same location and maintain filing integrity.
The footprint of a loaded Draftex Plan Trolley is considerably less than some other brands as there is no overhanging of the clamps over the back section.
Ease of assembly and disassembly makes them ideal for site relocation at the end of a project.
The 10 Clamp Capacity version is ideal for confined office or site shed environments while the 20 Clamp Capacity version provides maximum storage for floorspace used.

Product Range

Plan Clamps - DPCA1, DPCB1, DPCA0

Plan Trolleys - DPTA1, DPTA110, DPTA0, DPTA010

Wall Racks - DWR1000


The Draftex Range of Plan Filing Equipment consists of Trolleys, Wall Brackets and Clamps. The integral part of the system is the clamp and it’s design. The requirement of a good plan clamp is to hold from 1 to 100 sheets of paper securely. Then the loaded clamp must be able to be stored in a wall rack or trolley and easily removed and returned to the same location to maintain a filing sequence. Plans must be easily loaded in to the clamp and removed or replaced efficiently. Clamps should ideally match the paper sizes in use.


Plan filing is an important requirement of Architectural, Engineering and Construction Industry practice. The trolley and clamp system is a proven way of managing sets of drawings and having them available for easy access. The versatility of the system makes it suitable for the widest range of users from the smallest enterprise up to the largest corporate.


Draftex Plan Filing holds a commanding market share in the Australian market with over 50,000 plan clamps now in use. The combination of high quality, ergonomic design and low price has ensured market success. The two piece design of the Planhorse brand of clamp cannot match the ease of use, particularly the opening to load function, the wide range of clamping efficiency, the ergonomic handle placement and the all metal construction of the Draftex clamp. Other brands have kitchen drawer handles and plastic clips that they pivot from. The Draftex range cannot be beaten when all factors are considered even though it is probably the lowest price product available.

Other Terms for these Products

paper filing systems, vertical filing system, plan filing system, drawing storage systems, plan cabinet, plan filing, storage trolleys, plan storage systems, plan racks, plan holder, plan storage cabinets, mobile storage racks, clamp storage, plan filing systems, plans rack, plan file cabinets, drawing rack, drawing racks, plan holders, mobile storage trolley, vertical plan cabinets, trolley racks, clamp rack plans, planhold, vertical file cabinets, portable storage racks, planhorse, vertical plan cabinet, plan trolley, plan hanger stand, mobile storage trolleys, trolley plans, planhorse clamps, planhorse trolley, plan cabinets for sale, Planrack, Plan rack, Draftex Trolley, Arnos, vertiplan cabinets

Code Unit Description Dimensions Weight
DPTA110EachA1 10 Clamp Capacity1030L x 810W x 70H14000 (g)
DPTA1EachA1 20 Clamp Capacity1030L x 810W x 70H15000 (g)
DPTA010EachA0 10 Clamp Capacity1320L x 810W x 70H16000 (g)
DPTA0EachA0 20 Clamp Capacity1320L x 810W x 70H18000 (g)

Related Components
